Laser Laser trạng thái rắn 808nm Mô-đun Laser Diode 55W với nhiều bộ phát

Thông tin cơ bản
Nguồn gốc: Trung Quốc
Hàng hiệu: BWT
Chứng nhận: ISO9001
Số mô hình: K809DA5RN-55.00W
Số lượng đặt hàng tối thiểu: 1 mảnh/miếng
Thời gian giao hàng: 4-8 tuần
Điều khoản thanh toán: T/T
Khả năng cung cấp: 100.000 / năm
Thông tin chi tiết
Điểm nổi bật:

laser diode y tế

,

mô-đun laser mini


Mô tả sản phẩm

Features:

808nm wavelength

55W output power

400μm fiber core diameter

0.22 N.A.



Applications:

Solid-state laser pumping

Medical use

Material processing





Specifications(25℃) Symbol Unit K808DA5RN-55.00W
Minimum Typical Maximum

Optical Data





CW-Output Power Po W 55 - -
Center Wavelength λc nm 805 - 811
Threshold current Ith A - 1.8
Operating current Iop A - - 11
Operating voltage Vop V - - 14
Reverse Voltage Vre V - 17.5 -
Slope Efficiency η W/A - 7.4 -
Electrical-to-Optical Efficiency PE % - 48 -
Spectral width(FWHM) △​λ nm - 5 -
Back reflection isolation - dB - 30 -
Back reflection wavelength Range λ nm 1040 - 1200
Wavelength Shift with Temperature △​λ/△T nm/℃ - 0.3 -
Wavelength Shift with Current △λ/△A nm/A - 1 -
Fiber Data Core diameter Dcore µm   400
Cladding diameter Dclad um - 440 -
Buffer diameter Dbuf µm - 730 -
Numerical Aperture N.A - - 0.22 -
Fiber length lc m 1.4 1.5 1.6
Connector - - - SMA905 -
Fiber jacket - -   3.0mmPVC
Fiber Bend Radius - mm - 140 -
Thermistor Wavelength Range Rt (K Ω)/β(25℃) - 10±3%/3477 -
Others ESD Vesd V   - 500
Storage Temperature Tstg -20 - 70
Lead Soldering Temp Tls - - 260
Lead Soldering Time t sec - - 10
Operating case temperature Top 15 - 35
Relative Humidity RH % 15 - 75
